2A50, 7A52, 7050 aluminum alloy forgings for armor have the characteristics of high strength and light weight, and are suitable for armor applications. These alloys have excellent impact resistance and protection capabilities, providing reliable protection for armor systems while reducing overall weight and improving mobility and fuel efficiency.Welcome contact
Why choose Chalco 2A50 7A52 7050 Aluminum alloy forgings for armor?
- Chalco Aluminum can provide high-quality aluminum alloy forgings for armor, as well as high-quality technical services in the market, and has a deep knowledge base on how to support customers to meet future challenges.
- Quality could full meet Aluminum armor sheet plate standard—AMS, MIL, ASTM, AS, ISO, GJB 9566-2018, etc. standard
- Customer reference of aluminum alloy forgings for armor—UKROBORONPROM, ASELSAN, HEAVY INDUSTRIES TAXILA, Raytheon Company, SF Enginnering etc.
The Specs of 7050 7A52 2A50 aluminum alloy forgings for armor
| Alloy | Temper | Forging category |
| 2A50 | T6 | Forging category: according to the drawing |
| 7A52 | T6 | |
| 7050 | T74 |
Non-metallic inclusions are not allowed in the fracture structure of forgings, and the oxide film meet the requirements in the table below.
| Forging category | Inspection area m² | Requirements for Oxide Film in Fracture Tissue | |
| Total area mm² | Single point area mm² | ||
| Ⅰ | 0.01 | ≤4 | ≤2 |
| Ⅱ | 0.01 | ≤6 | ≤3 |
| Ⅲ | 0.01 | ≤8 | ≤3 |
The chemical composition of 7050 7A52 2A50 Aluminum alloy forgings for armor
| Element | Composition (%) | ||
| 2A50 | 7A52 | 7050 | |
| Si | 0.7-1.2 | 0.25 | ≤0.12 |
| Fe | 0.70 | 0.30 | 0.000-0.150 |
| Cu | 1.80-2.60 | 0.05-0.20 | 2.0-2.6 |
| Mn | 0.40-0.80 | 0.20-0.50 | ≤0.10 |
| Mg | 0.40-0.80 | 2.0-2.8 | 1.9-2.6 |
| Zn | 0.30 | 4.0-4.8 | 5.7-6.7 |
| Ti | 0.15 | 0.05-0.18 | ≤0.06 |
| Ni | 0.10 | - | - |
| Zr | 0.05-0.15 | 0.08-0.15 | |
| Cr | 0.15-0.25 | ≤0.04 | |
| Al | Remainder | Remainder | Remainder |
The mechanical properties of 7050 7A52 2A50 aluminum alloy forgings for armor
| Alloy | Supply and sample temper | Forging method | Sampling direction | Tensile strength Rm MPa | Yield strength Rp0.2 MPa | Elongation after break | Brinell hardness HBW |
| No less than | |||||||
| 2A50 | T6 | Hummer forging | portrait | 365 | — | 8.0 | 95 |
| horizontal | 345 | — | 6.0 | 95 | |||
| High direction | 335 | — | 4.0 | 95 | |||
| Die forging | portrait | 385 | 275 | 10.0 | 100 | ||
| horizontal | 365 | 245 | 7.0 | 100 | |||
| High direction | 345 | — | 5.0 | 100 | |||
| 7A52 | T6 | Die-forged, hummer -forged or rolled rings | Longitudinal (tangential to rolling ring) | 410 | 345 | 6 | 120 |
| Transverse (rolling ring axial direction) | 380 | — | 4 | 120 | |||
| High direction (rolling ring radial direction) | 360 | — | 2ª | 120 | |||
| 7050 | T74 | Hummer Forged or Rolled Rings | Longitudinal (tangential to rolling ring) | 475 | 406 | 9 | 140 |
| Transverse (rolling ring axial direction) | 468 | 399 | 4 | 140 | |||
| High direction (rolling ring radial direction) | 468 | 399 | 3 | 140 | |||
| ª When the weight of a single piece of forging or rolled ring is less than 30kg, the elongation after breaking not be less than 3%. | |||||||
Other military product series in Chalco
2024 7075 Al military profile
7039 Al military profile
2219 Al military profile
5083 Al military profile
Composed Al military plate
7039 Al military forging
Characteristics of 2A50 7A52 7050 aluminum alloy forgings for armor
High strength: The alloy forging has excellent strength, which can provide reliable armor protection and effectively resist external impact and damage.
Lightweight: Compared with traditional armor materials, aluminum alloy forgings have a lower density, which enables the armor system to reduce overall weight while ensuring strength, improving mobility and fuel efficiency.
Good impact performance: The alloy has excellent impact absorption and dispersion capabilities, which can effectively slow down and disperse the impact on armor from external forces such as explosions and impacts, providing effective protection.
Corrosion resistance: Aluminum alloy forgings have good corrosion resistance, can resist corrosion and oxidation under various harsh environmental conditions, and prolong the service life of the armor.
Strong plasticity: aluminum alloy has good plasticity, easy to forge and shape, and can meet the needs of armor of various complex shapes.
In summary, 2A50 7A52 7050 aluminum alloy forging for armor has the characteristics of high strength, light weight, good impact performance, corrosion resistance and strong plasticity, and is an ideal armor material.Quick Quote
Application of 2A50 7A52 7050 aluminum alloy forgings for armor
2A50 7A52 7050 aluminum alloy forgings for armor are mainly used in the following aspects.
Armored vehicles: This aluminum alloy forging is widely used in various armored vehicles, such as main battle tanks, armored personnel carriers, and armored reconnaissance vehicles. They are used in the manufacture of car bodies, doors, chassis and other critical components to provide effective shielding and protection against threats such as shrapnel, shells and explosions.
Military installations: In military installations, this aluminum alloy forging can be used for armoring buildings, equipment and facilities. This includes places such as military bases, command centers, storage areas for military equipment, etc., for additional protection and security.
To sum up, 2A50 7A52 7050 aluminum alloy forgings for armor are suitable for armored vehicles, aerospace and military facilities and other fields. Its light weight and high strength characteristics make it a reliable armor material, providing effective shielding and protection while reducing overall weight and improving mobility and fuel efficiency.Quick Quote
Aspects should be paid attention to when selecting 2A50 7A52 7050 aluminum alloy military forgings for armor
Strength and protection ability: ensure that the selected aluminum alloy forging has sufficient strength and protection ability, can effectively resist external impact and damage, and provide reliable armor protection.
Material quality and certification: ensure that selected aluminum alloy forgings meet relevant military standards and specifications and possess acceptable material quality and certification. You can view relevant documentation and warranty information provided by the manufacturer.
Adaptability and compatibility: ensure that the selected aluminum alloy forgings match the design and requirements of the target military equipment, can adapt to the shape and structure of the equipment, and are compatible with other components.
Reliability and durability: considering the reliability and durability of aluminum alloy forgings, they should be able to be used for a long time under various harsh environmental conditions and maintain their performance and protection characteristics.
Technical support and after-sales service: learn about the technical support and after-sales service provided by the manufacturer, including product warranty, repair and replacement, so as to ensure timely support and service when needed.
To sum up, when selecting 2A50 7A52 7050 aluminum alloy military forgings for armor, attention should be paid to strength and protection capabilities, material quality and certification, adaptability and compatibility, reliability and durability, as well as technical support and after-sales service. , to ensure the selection of high-quality products that meet the requirements.
Chalco can provide you the most comprehensive inventory of aluminum products and can also supply you customized products. Precise quotation will be provided within 24 hours.
