1050A 1070 1100 1350 aluminum wire rods are usually used in the manufacture of fasteners, such as screws, nuts, bolts and other fasteners. These aluminum wire rods are extruded or drawn and have good mechanical properties and processing properties.
Why choose Chalco 1050A 1070 1100 1350 aluminum wire rod for fasteners?
Production capacity
Chalco Aluminum is an enterprise integrating the design, development and precision testing of smelting, extrusion, and fine-drawn aluminum manufacturing. It can provide high-quality aluminum wire rods for 1050A 1070 1100 1350 fasteners, as well as high-quality technical services in the market, and has a profound knowledge base on how to support customers in coping with future challenges.
Certified product
We have passed the AS9100 certification required by the aviation industry and the IATF16949 certification required by the automotive industry, providing a strong guarantee for the quality of the aluminum wire rods used for fasteners produced by our company.
Chemical composition of aluminum rods for 1050A 1070 1100 1350 fasteners
| Element | Composition | |||
| 1050A | 1070 | 1100 | 1350 | |
| Si | ≤ 0.25 | ≤ 0.20 | ≤ 0.95 | ≤ 0.10 |
| Fe | ≤ 0.40 | ≤ 0.25 | ≤ 0.05 | ≤ 0.40 |
| Cu | ≤ 0.05 | ≤ 0.04 | - | ≤ 0.05 |
| Mn | ≤ 0.05 | ≤ 0.03 | - | ≤ 0.01 |
| Mg | ≤ 0.05 | ≤ 0.03 | - | ≤ 0.01 |
| Zn | ≤ 0.05 | ≤ 0.04 | ≤ 0.10 | ≤ 0.10 |
| Ti | ≤ 0.03 | ≤ 0.03 | - | - |
| Al | ≥ 99.50 | ≥ 99.70 | ≥ 99.00 | ≥ 99.50 |
Specifications for aluminum wire eods for 1050A 1070 1100 1350 fasteners
| 1050A Aluminum wire rod for fasteners | |
| Size | 1.0-15.0mm |
| Temper | H18 |
| Size Tolerance | ±0.02mm |
| Weight Coil | Above 50KGs |
| Function | Fastener |
| 1070 Aluminum wire rod for fasteners | |
| Size | 1.0-8.0mm |
| Temper | H32 |
| Size Tolerance | ±0.02mm |
| Weight Coil | Above 50KGs |
| Function | Fastener |
| 1100 Aluminum wire rod for fasteners | |
| Size | 1.0-15.0mm |
| Temper | H18 |
| Size Tolerance | ±0.02mm |
| Weight Coil | Above 50KGs |
| Function | Fastener |
| 1350 Aluminum wire rod for fasteners | |
| Size | 1.0-10.0mm |
| Temper | H14 |
| Size Tolerance | ±0.02mm |
| Weight Coil | Above 50KGs |
| Function | Fastener |
Product features of aluminum wire rods for 1050A 1070 1100 1350 fasteners
Excellent electrical conductivity: all these aluminum poles have good electrical conductivity, especially 1350 aluminum poles, which have the best electrical conductivity among pure aluminum. This makes them suitable for fastener applications such as electrical connectors, wires and cables where high electrical conductivity is required.
Good mechanical properties: after processing such as extrusion or drawing, these aluminum wire rods have moderate strength and toughness, which can meet the strength and stability requirements of fasteners. Although their mechanical properties are not as good as steel, they are very suitable for light-duty applications.
Good processing performance: 1050A 1070 1100 1350 aluminum wire rods are easy to process and form, which makes them more flexible and efficient in manufacturing fasteners of various shapes. For example, extrusion, drawing, cold working and other processes can be used to process these aluminum wire rods.
Lightweight: compared with steel, aluminum poles have a lower density, so the weight of fasteners can be reduced when used, which is especially beneficial for application scenarios that need to reduce overall weight, such as aerospace, automotive and other fields.
Good corrosion resistance: 1100 aluminum wire rod has good corrosion resistance, especially suitable for some fastener applications with high humidity or chemical corrosion environment.
Environmental protection: aluminum poles are recyclable materials, which are more environmentally friendly than disposable plastics, helping to reduce resource waste and environmental pollution.
Application of aluminum rods for 1050A 1070 1100 1350 fasteners
Screws and nuts: aluminum wire rods can be used to make various types of screws and nuts, especially for light duty and non-critical fasteners, such as household appliances, electronic equipment, etc.
Bolts: for some bolting applications with low strength requirements, aluminum wire rods can also be used for fabrication.
Electrical connectors: due to the excellent electrical conductivity of aluminum wire rods, especially 1350 aluminum wire rods, they are often used as conductive parts in the manufacture of electrical connectors.
Cables and wires: 1050A 1070 1100 1350 aluminum poles are widely used in the manufacture of cables and wires for power transmission lines and power transmission.
Insulation clamps: in electrical equipment, aluminum poles can be used to manufacture insulation clamps for supporting and securing insulation materials.
Wind power: in wind power plants, aluminum poles are also used, for example to hold components for power converters and generators.
Other mechanical components: in addition to the above applications, aluminum wire rods can also be used to manufacture various mechanical components such as furniture connectors, automotive parts, etc.
