Why choose Chalco aluminum rivets wire?
Authentication
Chalco products are manufactured in our state-of-the-art facility using a strict quality and environmental management system that is ISO certified, IATF16949 certification for the automotive industry, etc.Quick Quote
Production strength
Production and management in accordance with the international industry standards to ensure a long service life.
Production standard
GB/T 3195-2023Quick Quote
The specification of aluminum rivets wire
| Size | 1.6-10.0mm |
| Temper | O |
| Surface quality | No cracks, no burrs, no skinning, no bubbles, no bumps, no dents on the surface, No scratches, no triangular opening, no metal indentation, no non-metal indentation and no surface corrosion, oil spots, etc. |
5052 rivet wire diameter deviation
| Diameter | Allowable deviation | |||
| A grade | B grade | C grade | D grade | |
| ＞1.6-4.0 |
+0.000 -0.025 |
+0.025 -0.015 |
±0.025 |
+0.00 -0.05 |
| ＞4.0-6.0 |
+0.000 -0.030 |
+0.025 -0.025 |
±0.040 |
+0.00 -0.08 |
| ＞6.0-10.0 |
+0.000 -0.040 |
+0.050 -0.025 |
±0.060 |
+0.00 -0.12 |
Chemical component of Chalco aluminum rivets wire
| Element | Composition % |
| Al | Rest |
| Mg | 2.5-2.8 |
| Cu | 0.10 |
| Mn | 0.15-0.35 |
| Cr | 0.10 |
| Zn | 0.10 |
| Ti | 0.15 |
| Si | 0.25 |
| Fe | 0.40 |
| Other (most individual impurities) | 0.05 |
| Other (most total impurities) | 0.15 |
5052 mechanical properties of riveted aluminum wire
| Alloy | Supply temper | Sample temper | Diameter mm | Mechanical properties | |||
| tensile strength Rm MPa | yield strength Rp0.2 MPa | Elongation % | |||||
| A100mm | A250mm | ||||||
| No less than | |||||||
| 5056 | O | O | ≤220 | — | — | — | |
Advantages of Chalco 5052 aluminum rivets wire
Good corrosion resistance: 5052 aluminum alloy has excellent corrosion resistance and can resist corrosion in most common environments, including moisture, seawater and chemicals, so it is suitable for use in wet and corrosive environments.
High plasticity: 5052 aluminum alloy is an alloy with good plasticity, which is easy to process and form, and can be adapted to different shapes and sizes of rivets required.
Lightweight: aluminum is a lightweight metal, 5052 rivet aluminum wire has a lower density compared to materials such as steel, which can reduce the weight of the overall structure.
Moderate strength: 5052 aluminum alloy has a moderate level of strength among aluminum alloys and can meet the needs of many general engineering and structural applications.
Easy to weld: 5052 aluminum alloy has good weldability and can be welded to other aluminum alloys or the same material, providing greater design flexibility.
Wide applications: 5052 riveted aluminum wire is widely used in aerospace, automotive manufacturing, marine and construction applications, especially for projects requiring corrosion resistance and lighter weight.
Overall, 5052 Rivet Aluminum Wire is an excellent riveting material for a wide range of engineering and manufacturing applications requiring corrosion resistance, high plasticity and lighter weight. It is a common and reliable material choice for a wide range of applications.
Precautions for purchasing aluminum rivets wire
Material certification
Ensure that the purchased aluminum rivets wire meets relevant standards and obtains a qualified material certification certificate.
Specification requirements
Select the appropriate specification, size and shape according to actual needs to ensure that the purchased aluminum rivets wire can meet the specific aluminum rivets wire manufacturing requirements.
Surface quality
Check whether the surface of the purchased aluminum rivets wire is smooth, free of cracks, wear, oxidation or other surface defects, to ensure that the surface quality of the aluminum rivets wire meets the requirements.
Supplier reputation
Choose a reputable and experienced supplier to purchase to ensure that the purchased aluminum rivets wire is reliable in quality, reasonable in price and timely in delivery.
Storage requirements
Pay attention to the storage requirements of the aluminum rivets wire, keep it dry, avoid moisture, mechanical impact or other damage.
In short, when purchasing aluminum rivets wire, you need to pay attention to material certification, specification requirements, surface quality, supplier reputation and storage requirements, etc., to ensure that the purchased aluminum rivets wire are reliable in quality and meet the requirements.
Applications of Chalco aluminum rivets wire
5052 Rivet Aluminum Wire is a special type of aluminum alloy wire that is typically used in specific applications, some of which include:
Aerospace: 5052 Rivet Aluminum Wire is widely used in the aerospace industry for the manufacture of structural components, bolts, rivets, etc. for aircraft.
Automotive industry: riveted aluminum wire can be used to manufacture automotive components such as body structures, doors, hoods, etc. Due to its lightweight and high-strength characteristics, it helps to improve automotive fuel efficiency and performance.
Shipbuilding: 5052 riveted aluminum wire can be used in the manufacture of various components of ships, such as hulls, decks, etc. Its corrosion resistance makes it perform well in the marine environment.
Construction: this type of aluminum wire can also be used for building structures, door and window frames, curtain walls, etc. The lightweight nature of aluminum can reduce the dead weight of buildings, while providing weather resistance.
Electronic and electrical equipment: 5052 riveted aluminum wire can be used for electronic equipment shells, heat sinks, wires, etc., to help maintain the stability of the equipment and heat dissipation performance.
Packaging industry: riveted aluminum wire can be used to manufacture various types of packaging materials, such as aluminum foil bags and aluminum cans.
Chalco can provide you the most comprehensive inventory of aluminum products and can also supply you customized products. Precise quotation will be provided within 24 hours.
