5086 Aerospace Aluminum Sheet Plate

Quick Quote

Chalco adheres to high-quality aluminum production, contact us to obtain a quotation.

Contact us now

Why choose Chalco 5086 aircraft aluminum sheet plate?

Alloy 5086 aluminum plate exhibits higher strength compared to 5052 or 5083. Its excellent welding characteristics and superior corrosion resistance in seawater make it highly favored for marine applications.Quick Quote

As the largest manufacturer and supplier of 5086 H32 H116 Aluminum Sheet in China, Chalco maintains extensive product inventory. We support large-scale custom production and also offer small-batch stock delivery.

5086-aluminum-plate

Chalco is a professional manufacturer of aviation materials with AS9100 aviation certification and strictly adheres to the following AMS aviation standards.Quick Quote

Quality could full meet world wide aviation standard

QQ-A-250/7 5086 sheet and plate, ASTM B928, ASTM B632

Production and management comply with international aviation quality system certification

  • AS9100
  • ISO 45001
  • ISO 9001
  • NADCAP HT
  • NADCAP NDT
  • IATP16949

aerospace certification

The specification of 5086 H14 aircraft aluminum sheet plate

Chalco 5086 aluminum alloy specification
Alloy 5086
Temper O, H111, H112, H116, H321, H12, H14, H16, H18, H32, H34, H36
Thickness 0.8-200mm
Width 500-2800mm
Length 1000mm-12000mm (Can be cut)
Normal dimension 1250*2500mm, 1500mm*3000mm.
Standard QQ-A-250/7 5086 sheet and plate
Aluminum plate price Factory price

5086 H32 H116 Aluminum Sheet Hot Selling Sizes

5086 Aluminum Sheet is ASTM B928 and ASTM B632 certified, and Chalco offers Aluminum Sheet cut to size.Quick Quote

Description Thickness (in) Width*Length (in) Width*Length (ft)
0.063" Aluminum Sheet 5086-H116 0.063" 12" X 12" 1 X 1 ft
0.063" Aluminum Sheet 5086-H116 0.063" 12" X 24" 1 X 2 ft
0.063" Aluminum Sheet 5086-H116 0.063" 12" X 48" 1 X 4 ft
0.063" Aluminum Sheet 5086-H116 0.063" 24" X 24" 2 X 2 ft
0.063" Aluminum Sheet 5086-H116 0.063" 24" X 48" 2 X 4 ft
0.063" Aluminum Sheet 5086-H116 0.063" 36" X 48" 3 X 4 ft
0.063" Aluminum Sheet 5086-H116 0.063" 48" X 144" 4 X 12 ft
0.08" Aluminum Sheet 5086-H116 0.08" 60" X 120" 5 X 10 ft
0.09" Aluminum Sheet 5086-H32 0.09" 12" X 12" 1 X 1 ft
0.09" Aluminum Sheet 5086-H32 0.09" 12" X 24" 1 X 2 ft
0.09" Aluminum Sheet 5086-H32 0.09" 12" X 48" 1 X 4 ft
0.09" Aluminum Sheet 5086-H32 0.09" 24" X 24" 2 X 2 ft
0.09" Aluminum Sheet 5086-H32 0.09" 24" X 48" 2 X 4 ft
0.09" Aluminum Sheet 5086-H32 0.09" 36" X 48" 3 X 4 ft
0.09" Aluminum Sheet 5086-H32 0.09" 48" X 144" 4 X 12 ft
0.125" Aluminum Sheet 5086-H116 0.125" 48" X 96" 4 X 8 ft
0.125" Aluminum Sheet 5086-H116 0.125" 48" X 120" 4 X 10 ft
0.125" Aluminum Sheet 5086-H116 0.125" 48" X 144" 4 X 12 ft
0.125" Aluminum Sheet 5086-H32 0.125" 12" X 12" 1 X 1 ft
0.125" Aluminum Sheet 5086-H32 0.125" 12" X 24" 1 X 2 ft
0.125" Aluminum Sheet 5086-H32 0.125" 12" X 48" 1 X 4 ft
0.125" Aluminum Sheet 5086-H32 0.125" 24" X 24" 2 X 2 ft
0.125" Aluminum Sheet 5086-H32 0.125" 24" X 48" 2 X 4 ft
0.125" Aluminum Sheet 5086-H32 0.125" 36" X 48" 3 X 4 ft
0.125" Aluminum Sheet 5086-H32 0.125" 48" X 144" 4 X 12 ft
0.160" Aluminum Sheet 5086-H116 0.160" 60" X 240" 5 X 20 ft
0.160" Aluminum Sheet 5086-H32 0.160" 60" X 240" 5 X 20 ft
0.188" Aluminum Sheet 5086-H32 0.188" 60" X 240" 5 X 20 ft
0.188" Aluminum Sheet 5086-H32 0.188" 72" X 240" 6 X 20 ft
0.19" Aluminum Sheet 5086-H116 0.19" 48" X 120" 4 X 10 ft
0.19" Aluminum Sheet 5086-H116 0.19" 48" X 144" 4 X 12 ft
0.19" Aluminum Sheet 5086-H116 0.19" 60" X 144" 5 X 12 ft
0.19" Aluminum Sheet 5086-H116 0.19" 96" X 240" 8 X 20 ft
0.19" Aluminum Sheet 5086-H32 0.19" 12" X 12" 1 X 1 ft
0.19" Aluminum Sheet 5086-H32 0.19" 12" X 24" 1 X 2 ft
0.19" Aluminum Sheet 5086-H32 0.19" 12" X 48" 1 X 4 ft
0.19" Aluminum Sheet 5086-H32 0.19" 24" X 24" 2 X 2 ft
0.19" Aluminum Sheet 5086-H32 0.19" 24" X 48" 2 X 4 ft
0.19" Aluminum Sheet 5086-H32 0.19" 36" X 48" 3 X 4 ft
0.19" Aluminum Sheet 5086-H32 0.19" 48" X 144" 4 X 12 ft
0.190" Aluminum Sheet 5086-H32 0.190" 48" X 144" 4 X 12 ft
0.249" Aluminum Sheet 5086-H116 0.249" 12" X 12" 1 X 1 ft
0.249" Aluminum Sheet 5086-H116 0.249" 12" X 24" 1 X 2 ft
0.249" Aluminum Sheet 5086-H116 0.249" 12" X 48" 1 X 4 ft
0.249" Aluminum Sheet 5086-H116 0.249" 24" X 24" 2 X 2 ft
0.249" Aluminum Sheet 5086-H116 0.249" 24" X 48" 2 X 4 ft
0.249" Aluminum Sheet 5086-H116 0.249" 36" X 48" 3 X 4 ft
0.249" Aluminum Sheet 5086-H116 0.249" 48" X 144" 4 X 12 ft
0.249" Aluminum Sheet 5086-H116 0.249" 48" X 144" 4 X 12 ft
0.249" Aluminum Sheet 5086-H116 0.249" 60" X 240" 5 X 20 ft
0.249" Aluminum Sheet 5086-H116 0.249" 72" X 144" 6 X 12 ft
0.249" Aluminum Sheet 5086-H32 0.249" 12" X 12" 1 X 1 ft
0.249" Aluminum Sheet 5086-H32 0.249" 12" X 24" 1 X 2 ft
0.249" Aluminum Sheet 5086-H32 0.249" 12" X 48" 1 X 4 ft
0.249" Aluminum Sheet 5086-H32 0.249" 24" X 24" 2 X 2 ft
0.249" Aluminum Sheet 5086-H32 0.249" 24" X 48" 2 X 4 ft
0.249" Aluminum Sheet 5086-H32 0.249" 36" X 48" 3 X 4 ft
0.249" Aluminum Sheet 5086-H32 0.249" 48" X 144" 4 X 12 ft
0.313" Aluminum Sheet 5086-H32 0.313" 60" X 240" 5 X 20 ft
0.313" Aluminum Sheet 5086-H32 0.313" 96" X 240" 8 X 20 ft
0.375" Aluminum Sheet 5086-H116 0.375" 12" X 12" 1 X 1 ft
0.375" Aluminum Sheet 5086-H116 0.375" 12" X 24" 1 X 2 ft
0.375" Aluminum Sheet 5086-H116 0.375" 24" X 24" 2 X 2 ft
0.375" Aluminum Sheet 5086-H116 0.375" 24" X 48" 2 X 4 ft
1" Aluminum Sheet 5086-H116 1" 12" X 12" 1 X 1 ft
1" Aluminum Sheet 5086-H116 1" 12" X 24" 1 X 2 ft
1" Aluminum Sheet 5086-H116 1" 24" X 24" 2 X 2 ft
1" Aluminum Sheet 5086-H116 1" 24" X 48" 2 X 4 ft
1/2" Aluminum Sheet 5086-H116 1/2" 12" X 12" 1 X 1 ft
1/2" Aluminum Sheet 5086-H116 1/2" 12" X 24" 1 X 2 ft
1/2" Aluminum Sheet 5086-H116 1/2" 24" X 24" 2 X 2 ft
1/2" Aluminum Sheet 5086-H116 1/2" 24" X 48" 2 X 4 ft
3/16" Aluminum Sheet 5086-H32 3/16" 48" X 144" 4 X 12 ft
3/16" Aluminum Sheet 5086-H32 3/16" 48" X 192" 4 X 16 ft
3/4" Aluminum Sheet 5086-H116 3/4" 60" X 240" 5 X 20 ft

Mechanical properties of 5086 aerospace aluminum plates

Temper Room temperature test result
Tension strength/MPa Yield strength/MPa Elongation/% Hardness
O/H111 240-310 100 11-17 65
H112 240-250 100-105 8-12 65-69
H116/H321 275 195 8-10 81
H12 275-335 200 3-7 81
H14 300-360 240 2-4 90
H16 325-385 270 2 98
H18 345 290 1 104
H22/H32 275-335 185 5-10 80
H24/H34 300-360 220 4-8 88
H26/H36 325-385 250 3 96

These values are typical characteristics and may not meet your needs. If you have special needs pleaseQuick Quote

5086 Related Popular Products Inventory

Chemical composition of 5086 aircraft sheets

Chemical composition
Al REM
Si ≤0.4
Fe ≤0.5
Cu ≤0.1
Mn 0.2-0.7
Mg 3.5-4.5
Cr 0.05-0.25
Zn ≤0.25
Ti ≤0.15
Note: EACH≤0.05; TOTAL≤0.15

5086-aluminium-plate-sheet

Advantages of Chalco 5086 O aerospace alloy metal aluminium sheet

High strength: the 5086 aircraft aluminium plate has high strength and can withstand various loads and vibrations during flight, while maintaining a stable form.

Lighter: the 5086 H16 aircraft aluminum sheet is lighter than traditional steel and copper, helping the aircraft achieve lightweight design, load capacity and fuel efficiency.

Good corrosion resistance: the 5086 H24 aviation aluminum plate has excellent corrosion resistance, which can resist the influence of high temperature, high humidity, salt spray and other environment on its corrosion during the flight, and prolong the service life.

Good processing performance: 5086 H111 aviation aluminum plate has good processing performance, can be cold processing, hot processing, deep stamping and other processing methods to meet different production needs.Quick Quote

Easy to weld: the 5086 aircraft metal aluminum plate is easy to be welded and can be composed of composite materials with other materials to improve the comprehensive performance of the material.

Environmental protection: 5086 H32 aviation aluminum plate does not contain lead, mercury and other harmful substances, meet the environmental protection requirements, can meet the environmental protection requirements of the aviation field.

5086 aerospace aluminum plate

Precautions for purchasing 5086 alloy aluminum aerospace sheets

Plate specification and size: 5086 metal aviation aluminum sheet usually has different specifications and sizes, according to the specific application scenario and requirements, select the appropriate plate specifications and sizes. It can be tailored and customized as needed.

Plank thickness: the thickness of 5086 aircraft aluminum plate is also an important parameter. According to the need, select the appropriate plate thickness to meet the corresponding strength, stiffness and weight requirements.Quick Quote

Plate surface quality: the surface quality of the 5086 aircraft aluminum sheets also needs to be considered. Check the surface of the sheet for dents, oxidation, scratches and other quality problems to ensure the availability of the sheet.

Plank standards and certification: 5086 H22 aircraft aluminum sheet shall meet the relevant standards and certification requirements, such as AMS (American Society for Materials and Testing) standard and ASTM (American Society for Materials and Testing) standard. The relevant standards and certificates should be checked at the time of purchase.

Plate suppliers and brands: choose reputable, high-quality plate suppliers and brands, to ensure the quality of 5086 H26 aviation aluminum plate and service quality.

Logistics and packaging: when buying aluminum 5086 aircraft alloy sheet, you need to pay attention to transportation and packaging issues. Ensure that the board is not damaged during transportation, and select appropriate packing materials and methods.

key points for buying 5086 aerospace aluminum plate

Applications of Chalco 5086 aircraft grade aluminum sheet

Leather plate: 5086 aluminum aerospace plate can be used to manufacture aircraft skin, as a protective layer on the outer surface of the aircraft, can withstand a variety of loads and vibration during the flight, while maintaining a stable form.

Structural parts: the 5086 aircraft aluminum alloy plate can be used to manufacture various structural parts of aircraft, such as wing spars, body, flaps, etc., with high strength and rigidity, it can withstand a large number of loads and vibrations.

Fuel tank: 5086 H116 aircraft aluminum plate can be used to manufacture aircraft fuel tanks, has good corrosion resistance and sealing performance, can ensure the safety and stability of fuel supply.Quick Quote

Interior panel: 5086 H321 aircraft aluminum plate can be used to manufacture aircraft interior panels, such as seats, siding, ceiling, etc., with good surface finish and wear resistance, can improve passenger comfort.

In short, 5086 aviation aluminum plate sheet has a wide range of application prospects in aircraft aviation applications, can provide a good material basis for aircraft design and manufacturing.

application of 5086 aerospace aluminum plate
