6063 aluminum sheet for appearance-critical parts—clean bending (O/T4), reliable welding, and an anodize-ready, uniform surface with strong corrosion resistance.
We match 6063 extrusions for same-batch anodizing to control color. Meets ASTM B209 / EN 485, with EN 10204 3.1 and RoHS/REACH on request.
6063 aluminum sheet plate specifications
- ASTM B209 — Aluminum and aluminum-alloy sheet & plate (US)
- EN 485 / EN 573-3 — Rolled sheet & plate, chemical composition (EU)
- GB/T 3880 — Aluminum and aluminum-alloy rolled sheet & plate (China)
- EN 10204 3.1, RoHS/REACH certification available on request
In projects such as curtain walls, showcases, and doors & windows, using the same alloy for profiles and sheets helps avoid anodizing color differences.
Instant Quote6063 aluminum sheet plate stock
Chalco supplies hot-selling sizes of 6063 aluminum sheets from stock, cut to size as needed, and also supports small-batch or special-dimension customization.
Click the links below to jump directly to the stock sizes of 6063 aluminum sheets and plates in T6, T651, or T5 tempers.
6063 T6 aluminum sheet plate stock
6063-T6 aluminum sheet combines medium strength with excellent corrosion resistance and a smooth, anodize-ready surface.
Chalco maintains a range of popular thicknesses in stock and also offers cut-to-size service for your project needs.
| Description | Thickness (in) | Thickness (mm) | Width (in) | Length (in) | Weight (kg/pc) |
| 6063-T6 Aluminum Sheet | 0.019" | 0.483 | 59.050" | 118.110" | 5.863 |
| 6063-T6 Aluminum Sheet | 0.031" | 0.787 | 59.050" | 118.110" | 9.566 |
| 6063-T6 Aluminum Sheet | 0.039" | 0.991 | 59.050" | 118.110" | 12.035 |
| 6063-T6 Aluminum Sheet | 0.059" | 1.499 | 49.212" | 98.425" | 12.644 |
| 6063-T6 Aluminum Sheet | 0.059" | 1.499 | 59.050" | 118.110" | 18.206 |
| 6063-T6 Aluminum Sheet | 0.078" | 1.981 | 59.050" | 118.110" | 24.069 |
| 6063-T6 Aluminum Sheet | 0.098" | 2.489 | 49.212" | 98.425" | 21.002 |
| 6063-T6 Aluminum Sheet | 0.098" | 2.489 | 59.050" | 118.110" | 30.241 |
| 6063-T6 Aluminum Sheet | 0.118" | 2.997 | 49.212" | 98.425" | 25.289 |
| 6063-T6 Aluminum Sheet | 0.157" | 3.988 | 59.050" | 118.110" | 48.447 |
| 6063-T6 Aluminum Sheet | 0.157" | 3.988 | 49.212" | 98.425" | 33.647 |
| 6063-T6 Aluminum Sheet | 0.197" | 5.004 | 59.050" | 118.110" | 60.791 |
| 6063-T6 Aluminum Sheet | 0.197" | 5.004 | 49.212" | 98.425" | 42.219 |
| 6063-T6 Aluminum Sheet | 0.236" | 5.994 | 49.212" | 98.425" | 50.577 |
| 6063-T6 Aluminum Plate | 0.315" | 8.001 | 78.740" | 157.480" | 172.821 |
| 6063-T6 Aluminum Plate | 1.771" | 44.983 | 49.212" | 98.425" | 379.542 |
| 6063-T6 Aluminum Plate | 1.771" | 44.983 | 59.050" | 118.110" | 546.500 |
| 6063-T6 Aluminum Plate | 1.771" | 44.983 | 78.740" | 157.480" | 971.638 |
| 6063-T6 Aluminum Plate | 2.362" | 59.995 | 78.740" | 157.480" | 1295.882 |
| 6063-T6 Aluminum Plate | 2.559" | 64.999 | 78.740" | 157.480" | 1403.964 |
| 6063-T6 Aluminum Plate | 2.756" | 70.002 | 59.050" | 118.110" | 850.454 |
| 6063-T6 Aluminum Plate | 2.756" | 70.002 | 78.740" | 157.480" | 1512.046 |
| 6063-T6 Aluminum Plate | 3.937" | 100.000 | 78.740" | 157.480" | 2159.987 |
| 6063-T6 Aluminum Plate | 4.724" | 119.990 | 78.740" | 157.480" | 2591.765 |
| 6063-T6 Aluminum Plate | 6.299" | 159.995 | 78.740" | 157.480" | 3455.870 |
| 6063-T6 Aluminum Plate | 6.693" | 170.002 | 78.740" | 157.480" | 3672.033 |
| 6063-T6 Aluminum Plate | 7.480" | 189.992 | 78.740" | 157.480" | 4103.811 |
| 6063-T6 Aluminum Plate | 7.874" | 200.000 | 78.740" | 157.480" | 4319.974 |
Need to estimate the weight of your order? Use our aluminum plate calculator to get quick results.
Instant Quote6063 T651 aluminum sheet plate stock
6063-T651 aluminum plate is supplied in a stress-relieved condition, offering higher strength, better dimensional stability, and reduced residual stress compared with standard T6.
It is the preferred choice for thick plates that require precision machining, stable flatness, and long-term reliability.
| Description | Thickness (in) | Thickness (mm) | Width (in) | Length (in) | Weight (kg/pc) |
| 6063-T651 Aluminum Sheet | 0.156" | 3.988 | 59.05" | 118.11" | 48.4 |
| 6063-T651 Aluminum Sheet | 0.188" | 5.004 | 59.05" | 118.11" | 60.8 |
| 6063-T651 Aluminum Sheet | 0.313" | 8.001 | 59.05" | 118.11" | 97.3 |
| 6063-T651 Aluminum Plate | 0.391" | 9.982 | 78.74" | 157.48" | 214.5 |
| 6063-T651 Aluminum Plate | 0.469" | 11.989 | 59.05" | 118.11" | 145.7 |
| 6063-T651 Aluminum Plate | 0.594" | 14.986 | 59.05" | 118.11" | 182.2 |
| 6063-T651 Aluminum Plate | 0.625" | 16.002 | 78.74" | 157.48" | 342.9 |
| 6063-T651 Aluminum Plate | 0.703" | 17.983 | 59.05" | 118.11" | 218.5 |
| 6063-T651 Aluminum Plate | 0.875" | 22.005 | 59.05" | 118.11" | 267.5 |
| 6063-T651 Aluminum Plate | 0.984" | 24.995 | 78.74" | 157.48" | 539.9 |
| 6063-T651 Aluminum Plate | 1.188" | 29.997 | 78.74" | 157.48" | 651.8 |
| 6063-T651 Aluminum Plate | 1.781" | 44.983 | 78.74" | 157.48" | 977.1 |
| 6063-T651 Aluminum Plate | 2.172" | 55.003 | 78.74" | 157.48" | 1191.6 |
| 6063-T651 Aluminum Plate | 2.375" | 59.995 | 78.74" | 157.48" | 1303.0 |
| 6063-T651 Aluminum Plate | 2.750" | 70.002 | 78.74" | 157.48" | 1508.8 |
| 6063-T651 Aluminum Plate | 3.156" | 79.997 | 78.74" | 157.48" | 1731.5 |
| 6063-T651 Aluminum Plate | 3.563" | 89.994 | 78.74" | 157.48" | 1954.8 |
| 6063-T651 Aluminum Plate | 3.750" | 95.008 | 78.74" | 157.48" | 2057.4 |
| 6063-T651 Aluminum Plate | 4.344" | 109.982 | 78.74" | 157.48" | 2383.3 |
| 6063-T651 Aluminum Plate | 5.500" | 139.991 | 78.74" | 157.48" | 3017.5 |
| 6063-T651 Aluminum Plate | 7.094" | 179.982 | 78.74" | 157.48" | 3892.0 |
| 6063-T651 Aluminum Plate | 7.875" | 200.000 | 78.74" | 157.48" | 4320.5 |
For accurate weight and cost planning, click here to use our aluminum plate calculator. It opens in a new tab for your convenience.
6063-T5 aluminum sheet plate stock
6063-T5 aluminum offers excellent processability, formability, and a smooth anodize-ready surface. It is widely chosen for curtain walls, window frames, decorative panels, and other applications where good corrosion resistance and appearance are more important than high strength.
Chalco supplies hot-selling thicknesses in stock and supports cut-to-size or custom dimensions on request.
Note: The widths shown below (0.394″–1.968″) are narrow strip sizes (slit/edge-trimmed), not standard sheet widths; wider sheets and custom slit-to-width are available on request.
Instant Quote| Description | Thickness (in) | Thickness (mm) | Width (in) | Length (in) | Weight (kg/pc) |
| 6063-T5 Aluminum Sheet | 0.078" | 1.981 | 0.788" | 118.110" | 0.321 |
| 6063-T5 Aluminum Sheet | 0.078" | 1.981 | 0.984" | 118.110" | 0.401 |
| 6063-T5 Aluminum Sheet | 0.078" | 1.981 | 1.575" | 118.110" | 0.642 |
| 6063-T5 Aluminum Sheet | 0.078" | 1.981 | 1.968" | 118.110" | 0.802 |
| 6063-T5 Aluminum Sheet | 0.118" | 2.997 | 0.394" | 118.110" | 0.243 |
| 6063-T5 Aluminum Sheet | 0.118" | 2.997 | 0.590" | 118.110" | 0.364 |
| 6063-T5 Aluminum Sheet | 0.118" | 2.997 | 0.788" | 118.110" | 0.486 |
| 6063-T5 Aluminum Sheet | 0.118" | 2.997 | 0.984" | 118.110" | 0.607 |
| 6063-T5 Aluminum Sheet | 0.118" | 2.997 | 1.181" | 118.110" | 0.728 |
| 6063-T5 Aluminum Sheet | 0.118" | 2.997 | 1.575" | 118.110" | 0.971 |
| 6063-T5 Aluminum Sheet | 0.118" | 2.997 | 1.968" | 118.110" | 1.214 |
| 6063-T5 Aluminum Sheet | 0.157" | 3.988 | 0.788" | 118.110" | 0.647 |
| 6063-T5 Aluminum Sheet | 0.157" | 3.988 | 0.984" | 118.110" | 0.807 |
| 6063-T5 Aluminum Sheet | 0.157" | 3.988 | 1.181" | 118.110" | 0.969 |
| 6063-T5 Aluminum Sheet | 0.157" | 3.988 | 1.575" | 118.110" | 1.292 |
| 6063-T5 Aluminum Sheet | 0.157" | 3.988 | 1.968" | 118.110" | 1.615 |
Can't find the right size? Chalco also offers cut-to-size service and full customization to match your project requirements.
We also supply 6063 aluminum flat bars. View flat bar stock sizes.
Instant Quote6063 aluminum sheet plate product video
A 30-second overview of 6063-T5 aluminum sheet: surface finishes (brushed/sandblasted), clean bending and cutting, flatness checks, anodizing examples, PE protective film, and export-grade packing.
6063 aluminum sheet plate chemical composition
| Element | Content (wt%) |
| Si | 0.20 – 0.60 |
| Fe | ≤ 0.35 |
| Cu | ≤ 0.10 |
| Mn | ≤ 0.10 |
| Mg | 0.45 – 0.90 |
| Cr | ≤ 0.10 |
| Zn | ≤ 0.10 |
| Ti | ≤ 0.10 |
| Al | ~98.9 (Balance) |
Mechanical properties of 6063 aluminum sheet plate
| Temper | Tensile Strength (psi / MPa) | Yield Strength (psi / MPa) | Elongation (% in 2″) | Brinell Hardness (HBW) | Thermal Conductivity (W/m·K) | Electrical Conductivity (% IACS) |
| O | 16,000 / 110 | 8,000 / 55 | 18 | ~30 | 201 | 52 |
| T4 | 22,000 / 150 | 10,000 / 69 | 12 | ~35 | 201 | 52 |
| T5 | 27,000 / 186 | 21,000 / 145 | 12 | ~60 | 201 | 52 |
| T6 | 31,000 / 214 | 27,000 / 186 | 8 | ~60 | 201 | 52 |
6063 aluminum sheet plate equivalent grades
| UNS | WNr | DIN | EN | ISO | BS (old) | USA (AA) |
| A96063 | 3.32206 | AlMgSi0.5 | EN AW-6063 / AlMg0.7Si | AlMg0.7Si | HE9 | AA 6063 |
Anodizing & color consistency
To minimize color variation between sheets and matching extrusions, we offer same-batch anodizing in 6063 with clear, champagne, bronze, or black finishes.
- Co-anodize sheets & extrusions in the same lot; keep surface prep unified (brushed #180/#240 or sandblast 80–120 mesh).
- Typical film thickness: 10–15 µm (decorative), ~18 µm (architectural Class I), ≥25 µm (hard anodizing).
- Pre-production samples for color approval; optional ΔE target on request; PE film + export packing to protect finish.
RFQ tip: specify alloy/temper, finish & color, anodic film thickness, and whether sheets/extrusions must be anodized in the same batch.
If you are looking for anodized aluminum sheet, please click here.
Advantages of 6063 aluminum sheet plate
- Anodize-ready surface: delivers uniform color after brushing or sandblasting; ideal for visible parts.
- Excellent formability: easy bending in O/T4; parts can be age-hardened to T5/T6 after forming for added strength.
- Corrosion resistance: reliable for outdoor architectural use and humid environments.
- Good weldability: TIG/MIG welding with stable results and clean finishes.
- Color matching: sheets can be anodized in the same batch as 6063 extruded frames to minimize shade variation.
Applications of 6063 aluminum sheet plate
- Architectural panels & cladding: curtain walls, façades, soffits, louvers, trims, door/window infill panels.
- Displays & signage: lightboxes, wayfinding signs, retail showcases, exhibition panels.
- Enclosures & cabinets: equipment housings, electronics covers, rack panels.
- Furniture & interior décor: decorative panels, edging/trim, fixtures.
- Projects needing color consistency with extrusions: same-batch anodizing with 6063 profiles.
Packaging and transportation of 6063 aluminum sheet plate
- Interleave with paper/PE film; wrap with plastic or kraft paper with desiccants.
- Reinforced wooden pallets, steel straps, edge/corner guards to keep flatness.
- Export packing: fumigated wooden crates/pallets with clear shipping marks.
- Custom options on request (double-side PE film, VCI paper, pallet height limits, etc.).
- Incoterms: EXW, FOB, CIF, DAP, DDP (selected countries/regions).
- Shipping: Sea (FCL/LCL), air, express; stock ships fast, custom per schedule.
- Payment: T/T (e.g., 30/70), L/C at sight; PayPal for samples. Docs: CI, PL, B/L or AWB; EN 10204 3.1, RoHS/REACH on request.
Why choose Chalco for 6063 aluminum sheet plate
- Capacity: SMS Siemag 6-high mill; widths up to 2,650 mm, thicknesses up to 500 mm.
- Speed: stock ships ~1 week; custom 7–35 days; projects up to ~8,500 MT.
- Compliance: ASTM B209 / EN 485 / EN 573-3 / GB/T 3880; EN 10204 3.1; RoHS/REACH; optional UT (ASTM B548).
- Finishing: brushed/sandblasted + anodizing/hard anodizing; same-batch anodizing with 6063 extrusions.
- Processing: cut-to-size, CNC, drilling, chamfering; small batches and special dimensions welcome.
- Logistics: export-grade packing; EXW/FOB/CIF/DAP/DDP (selected regions).
Chalco other hot-selling aluminum sheet plate in stock
Choosing between 6061, 6063, and 6082 aluminum depends on your project needs: 6061 offers higher strength and excellent machinability, 6063 is preferred for anodizing quality and architectural appearance, and 6082 provides superior strength for structural applications. Learn more: See 6061 sheet & plate | See 6082 sheet & plate
6061 Aluminum Sheet
6082 Aluminum Sheet
6063 Aluminum Extrusions
1050 Aluminum Sheet
1060 Aluminum Sheet
3003 Aluminium Sheet
5052 Aluminum Sheet
5083 Aluminum Plate
5086 Aluminum Plate
6063 aluminum sheet plate FAQ
What is 6063 aluminum used for?
Appearance-critical panels and light structures: curtain walls, doors & windows, displays/signage, enclosures, and parts that need an anodize-ready surface.
6063-T5 vs 6063-T6 vs T651 — what's the difference?
T5: aged after forming; better bendability. T6: solution heat-treated + aged; higher strength. T651: T6 + stress-relieved (stretched), preferred for thick plates needing machining stability and flatness.
Do you stock 4×8 and cut-to-size?
Yes. Popular sizes are in stock; we also cut to size. Jump to sizes: T6 | T651 | T5.
How is price calculated? What's the price per pound?
Pricing depends on LME aluminum + regional premium, thickness/width/length, temper, finish (e.g., anodizing), and cutting. Use our aluminum plate calculator and click Instant Quote for a firm offer.
Can you match anodizing color with extrusions?
Yes. We can co-anodize 6063 sheets and 6063 extruded profiles in the same batch to minimize color difference (ΔE), with decorative or hard-anodizing options.
Do you ship worldwide?
Yes. We offer EXW, FOB, CIF, DAP, and DDP to selected countries, with export-grade packing and full documents.
